KOLD-DRAFT Commercial Ice Machine GT560
Product Description
KOLD-DRAFT GT560 Ice Machine
Produces up to 520 lbs of ice, available in half cube or full cube. Available in air cooled or water cooled.
Dimensions: 30.1" x 25.7" x 30.7"
Refrigeration: R-404A-HFC
Plumbing:
3/4" FPT potable water inlet.
1" FPT bin drain.
3/4" I.D. flex tubing cuber drain.
3/8" FPT condenser (liquid-cooled) inlet.
1/2" FPT condenser (liquid-cooled) outlet.
Exterior Finish:
300 Series stainless steel.
Clearance Requirements: Allow 4" left side, 4" right side and back, and 1" top for ventilation and utility connections.
Condenser Heat Rejection: BTUH/kW/Ton
6,500/1.91/0.54 avg.
8,750/2.6/0.729 peak
Produces up to 520 lbs of ice, available in half cube or full cube. Available in air cooled or water cooled.
Dimensions: 30.1" x 25.7" x 30.7"
Refrigeration: R-404A-HFC
Plumbing:
3/4" FPT potable water inlet.
1" FPT bin drain.
3/4" I.D. flex tubing cuber drain.
3/8" FPT condenser (liquid-cooled) inlet.
1/2" FPT condenser (liquid-cooled) outlet.
Exterior Finish:
300 Series stainless steel.
| Min | Max | |
| Room Air Temp | 45ºF (7ºC) | 110ºF (43ºC) |
| Water Temp | 45ºF (7ºC) | 90ºF (32ºC) |
| Voltage 208-230 | 198V | 253V |
| Voltage 115 | 104V | 126V |
| Portable Water Pressure | 20 PSIG (137 kPa) | 100 PSIG (689 kPa) |
| Liquid-Cooled Condenser Pressure | 20 PSIG (137 kPa) | 100 PSIG (689 kPa) |
Clearance Requirements: Allow 4" left side, 4" right side and back, and 1" top for ventilation and utility connections.
Condenser Heat Rejection: BTUH/kW/Ton
6,500/1.91/0.54 avg.
8,750/2.6/0.729 peak
